SICK DFS60B-S4PA10000 - Rotation-Position-Detect/Programmable-TTL-Pulse-Output - IP67 Aluminum M23 Solid Shaft 10000PPR Rotary Encoder
DFS60B-S4PA10000 HTL High-Res Incremental Encoder
The DFS60B-S4PA10000 is a 60mm incremental encoder featuring HTL 10-32V operation, 10,000 pulses per revolution, clamp flange design, 10mm solid shaft, axial M12 connection, and IP65/IP67 protection rating.
Application & Performance Advantages
Provides high-resolution speed and position pulse feedback to drives and PLCs for applications including printing, winding, and servo control loops. HTL interface provides excellent EMI resistance, while IP-rated construction ensures reliable operation in harsh industrial environments.
Product Specifications
| Parameter |
Specification |
| Model / Order No. |
DFS60B-S4PA10000 / 1036720 |
| Product Type |
Incremental encoder, programmable |
| Pulses per Revolution |
10,000 (1 - 10,000 programmable) |
| Output Interface |
TTL / HTL (programmable, factory TTL) |
| Supply Voltage |
4.5 … 32 V DC |
| Max. Speed |
9,000 rpm |
| Shaft Type / Diameter |
Solid shaft / 10 mm × 19 mm |
| Connection |
M23, 12-pin radial |
| Enclosure / IP Rating |
IP65 / IP67 |
| Operating Temperature |
-40 … +100 °C |
